产品名称：High temperature control cableKFFR
浏览：
添加时间：2024-06-05 15:39:00
推荐度：

介绍：

耐高温电缆应用于航天航空、电力、石油、化工、冶金等行业中有电磁干扰环境的控制、监控回路及配电装置中信号传输、控制及测量的连接，电器仪表、自动化设备、成套控制柜、机械工程、照明工程等需要弯曲移动的场合

High temperature resistant cables are used in industries such as aerospace, power, petroleum, chemical, metallurgy, etc. for the control and monitoring of electromagnetic interference environments, as well as the connection of signal transmission, control, and measurement in distribution devices. They are also used in electrical instruments, automation equipment, complete control cabinets, mechanical engineering, lighting engineering, and other situations that require bending and movement

产品结构：

Product structure:

导体：多股裸铜丝绞合(镀锡或镀银铜丝可选)，符合GB/T 3956-2008及IEC 60228：2004第5类导体

Conductors: Stranded bare copper wire (tin or silver plated copper wire optional), in accordance with GB/T 3956-2008 and IEC 60228:2004 Class 5 conductors

绝缘：聚全氟乙丙烯/聚四氟乙烯/其它氟塑料

Insulation: perfluoroethylene propylene/polytetrafluoroethylene/other fluoroplastics

芯线：芯线绞合成缆，芯线颜色符合GB/T 5023.1及JB/T 8734.1中的优先色谱选用

Core wire: The core wire is twisted into a cable, and the color of the core wire complies with the priority chromatographic selection in GB/T 5023.1 and JB/T 8734.1

彩色或编码芯线，3芯以上带黄绿双色线（可选）

Colored or coded core wire, 3 or more cores with yellow green dual color wire (optional)

屏蔽：镀锡或镀银铜线编织，编织密度≥80%

Shielding: Tin or silver plated copper wire weaving, weaving density ≥ 80%

护套：聚全氟乙丙烯/聚四氟乙烯/其它氟塑料

Sheath: perfluoroethylene propylene/polytetrafluoroethylene/other fluoroplastics

护套颜色：黑色或红色，可根据客户需要定制各种颜色

Sheath color: black or red, various colors can be customized according to customer needs

KFFRP高温电缆规格

KFFRP High Temperature Cable Specifications

高温控制电缆　　　　　

High temperature control cable
