产品名称：High temperature compensation wire KX-FPFP
浏览：
添加时间：2024-07-23 10:06:36
推荐度：

介绍：

一.执行标准

1、 Execution standards

K KX-FPFP -2*2*1.0补偿导线按照GB/T4989标准制造。补偿电缆按照JB/T7495标准制造。

The K KX-FPFPFP-2 * 2 * 1.0 compensation wire is manufactured according to the GB/T4989 standard. The compensating cable is manufactured according to JB/T7495 standard.

阻燃及耐火特性符合GB/T19666-2005标准规定。

The flame retardant and fire-resistant properties comply with the GB/T19666-2005 standard.

二.适用范围

2、 Scope of application

KX-FPFP -2*2*1.0补偿导线广泛适用于冶金、化工、石油、发电以及科研等部门采用热电偶方法测量温度的场合。用于热电偶与测温显示仪表之间的连接。

KX-FPFPFP-2 * 2 * 1.0 compensation wire is widely used in metallurgy, chemical, petroleum, power generation, and scientific research departments to measure temperature using thermocouple methods. Used for connecting thermocouples and temperature display instruments.

三.型号、名称、分度号及配套用热电偶类型

3、 Model, name, graduation number, and matching thermocouple type

KX-FF 氟塑料绝缘氟塑料护套普通级K分度热电偶用补偿电缆

KX-FF Fluoroplastic Insulated Fluoroplastic Sheath Compensation Cable for Ordinary Grade K-Scale Thermocouples

KX-FPF 氟塑料绝缘氟塑料护套铜丝编织分屏蔽普通级K分度热电偶用补偿电缆

KX-FPF fluoroplastic insulated fluoroplastic sheathed copper wire braided shielded compensating cable for ordinary grade K-index thermocouples

KX-FPFP 氟塑料绝缘氟塑料护套铜丝编织分屏蔽及总屏蔽普通级K分度热电偶用补偿电缆

KX-FPFP Fluoroplastic Insulated Fluoroplastic Sheath Copper Wire Braided Partial Shielding and Total Shielding Compensation Cable for Ordinary Grade K-Scale Thermocouples

KX-FFP 氟塑料绝缘氟塑料护套铜丝编织总屏蔽普通级K分度热电偶用补偿电缆

KX-FFP fluoroplastic insulated fluoroplastic sheathed copper wire braided total shielding compensation cable for ordinary grade K-index thermocouples

KXS-FF 氟塑料绝缘氟塑料护套精密级K分度热电偶用补偿电缆

KXS-FF Fluoroplastic Insulation Fluoroplastic Sheath Precision Grade K-Scale Thermocouple Compensation Cable

KXS-FPF 氟塑料绝缘氟塑料护套铜丝编织分屏蔽精密级K分度热电偶用补偿电缆

KXS-FPF Fluoroplastic Insulated Fluoroplastic Sheath Copper Wire Braided Shielding Precision Grade K Index Thermocouple Compensation Cable

KXS-FPFP 氟塑料绝缘氟塑料护套铜丝编织分屏蔽及总屏蔽精密级K分度热电偶用补偿电缆

KXS-FPFP Fluoroplastic Insulated Fluoroplastic Sheath Copper Wire Braided Partial Shielding and Total Shielding Compensation Cable for Precision Grade K Index Thermocouples

KXS-FFP 氟塑料绝缘氟塑料护套铜丝编织总屏蔽精密级K分度热电偶用补偿电缆

KXS-FFP Fluoroplastic Insulation Fluoroplastic Sheath Copper Wire Braided Total Shielding Precision Grade K-Scale Thermocouple Compensation Cable

KX-FP3F 氟塑料绝缘铝/塑复合带分屏蔽氟塑料护套普通级K分度热电偶用补偿电缆

KX-FP3F Fluoroplastic Insulated Aluminum/Plastic Composite Strip Shielded Fluoroplastic Sheath Compensation Cable for Ordinary Grade K-Scale Thermocouples

KX-FP3FP3 氟塑料绝缘铝/塑复合带分屏蔽及总屏蔽氟塑料护套普通级K分度热电偶用补偿电缆

KX-FP3FP3 Fluoroplastic Insulated Aluminum/Plastic Composite Strip with Partial Shielding and Total Shielding Fluoroplastic Sheath Compensation Cable for Ordinary Grade K-Scale Thermocouples

KX-FFP3 氟塑料绝缘氟塑料护套铜丝编织铝/塑复合带总屏蔽普通级K分度热电偶用补偿电缆

KX-FFP3 Fluoroplastic Insulated Fluoroplastic Sheath Copper Wire Braided Aluminum/Plastic Composite Strip Total Shielding Compensation Cable for Ordinary Grade K-Scale Thermocouples

KXS-FP3F 氟塑料绝缘铝/塑复合带分屏蔽氟塑料护套精密级K分度热电偶用补偿电缆

KXS-FP3F Fluoroplastic Insulated Aluminum/Plastic Composite Strip Shielded Fluoroplastic Sheath Precision Grade K-Scale Thermocouple Compensation Cable

KXS-FFP3 氟塑料绝缘及护套铝/塑复合带总屏蔽精密级K分度热电偶用补偿电缆

KXS-FFP3 Fluoroplastic Insulation and Sheath Aluminum/Plastic Composite Strip Total Shielding Precision Grade K Index Thermocouple Compensation Cable

KXS-FP3FP3 氟塑料绝缘铝/塑复合带分屏蔽及总屏蔽氟塑料护套精密级K分度热电偶用补偿电缆

KXS-FP3FP3 Fluoroplastic Insulated Aluminum/Plastic Composite Strip Shielding and Total Shielding Fluoroplastic Sheath Precision Grade K-Scale Thermocouple Compensation Cable

注：

Note:

1、其它型号补偿电缆EX、SC、KC、NC、NX、BC、TX、JX，只需改写型号的第一项，如EX-FF EX-FPF等。

1. Other models of compensating cables EX SC、KC、NC、NX、BC、TX、JX， Just rewrite the first item of the model, such as EX-FF EX-FPF, etc.

2、对于铜带屏蔽的电缆只需将型号中的P3改写成P2即可，如KX-FP2F即是氟塑料绝缘铜带绕包分屏蔽氟塑料护套普通级K分度热电偶用补偿电缆。

2. For copper tape shielded cables, simply rewrite P3 in the model to P2. For example, KX-FP2F is a compensating cable for fluoroplastic insulated copper tape wrapped and shielded fluoroplastic sheathed ordinary grade K-index thermocouples.

3、还有一些特制的聚四氟乙烯薄膜与玻璃丝复合绝缘及护套的高温补偿电缆，如：KXHF4

3. There are also some special high-temperature compensation cables with composite insulation and sheath of polytetrafluoroethylene film and glass fiber, such as KXHF4

表1

Table 1

型号	名称	分度号	配套用热电偶类型	绝缘层颜色
型号	名称	分度号	配套用热电偶类型	正极	负极
SC	铜－铜镍0.6补偿型电缆	S	铂铑₁₀－铂热电偶	红	绿
RC	铜－铜镍0.6补偿型电缆	R	铂铑₁₃－铂热电偶	红	绿
KCA	铁－铜镍22补偿型电缆	K	镍铬－镍硅热电偶	红	蓝
KCB	铜－铜镍40补偿型电缆			红	蓝
KX	镍铬10－镍硅3延长型电缆			红	黑
NC	铁－铜镍18补偿型电缆	N	镍铬硅－镍硅热电偶	红	灰
NX	镍铬14硅－镍硅延长型电缆	N	镍铬硅－镍硅热电偶	红	灰
EX	镍铬10－镍硅45延长型电缆	E	镍铬－铜镍热电偶	红	棕
JX	铁－铜镍45补偿型电缆	J	铁－铜镍热电偶	红	紫
TX	铜－铜镍45补偿型电缆	T	铜－铜镍热电偶	红	白
