产品名称：YGPB-6KV bucket wheel machine reclaimer stacker special flat
浏览：
添加时间：2025-04-01 16:46:56
推荐度：

介绍：

本产品适用于港口随堆取料机装、卸货物时移动的场合．起信号控制和动力传输的作用。也适用于需经常往复运动作业的其它设备。

This product is suitable for situations where the port stacker reclaimer moves during loading and unloading of goods. It plays a role in signal control and power transmission. It is also applicable to other equipment that requires frequent reciprocating motion operations.

高压扁电缆，港口用扁型硅橡胶软电缆，煤场斗轮机用6KV，10KV 港口用扁型硅橡胶软电缆10KV 港口用扁型硅橡胶软电缆为额定电压6KV，10KV移动配电装置及港口起重运输机械用铜芯硅橡胶绝缘硅橡胶护套扁型软电缆。

High voltage flat cables, flat silicone rubber flexible cables for ports, 6KV and 10KV flat silicone rubber flexible cables for coal yard bucket wheel machines, 10KV flat silicone rubber flexible cables for ports with rated voltage of 6KV, copper core silicone rubber insulated silicone rubber sheathed flat flexible cables for 10KV mobile distribution equipment and port lifting and transportation machinery.

产品结构：

Product Structure:

1）信号控制扁电缆：导电线芯+绝缘层+内称层+屏蔽层+保护层+外护层

1) Signal control flat cable: conductive core+insulation layer+inner layer+shielding layer+protective layer+outer protective layer

2）动力传输扁电缆：导电线芯+内半导电层+绝缘层+外半导电层+铜丝编织与加强层+外护层

2) Power transmission flat cable: conductive core+inner semiconductive layer+insulation layer+outer semiconductive layer+copper wire braided and reinforced layer+outer protective layer

型号model	产品名称product name	用途purpose	导体长期允许工作温度Long term allowable operating temperature for conductors ℃	额定电压rated voltageV	标称截面Nominal cross-sectionmm2
YGPB	斗轮机专用扁电缆Special flat cable for bucket wheel machine取料机专用扁电缆Special flat cable for reclaimer堆料机专用扁电缆Special flat cable for stacker	适用于斗轮机、取料机、堆料机等重型设备做动力传输线，亦适用于各类起重设备Suitable for heavy-duty equipment such as bucket wheel machines, reclaimers, and stackers as power transmission lines, as well as various types of lifting equipment	-40 ~ +90	6000 10000	10 ~ 240

电缆结构/尺寸表 Cable Structure/Size Table

型号model	芯数x截面Number of cores x cross-section mm2	电缆外型尺寸Cable dimensions	电缆参考重量Reference weight of cableKG/KM
高height mm	宽 wide mm
YGPB-6KV	3x16+3x16/3	27	63	2815
3x25+3x16/3	29	68	4100
3x35+3x16/3	31	72	4750
3x50+3x16/3	34	77	6300
3x70+3x25/3	36	83	7380
3x95+3x35/3	38	90	7800
3x120+3x35/3	40	98	9500
YGPB-10KV	3x16+3x16/3	32	73	3700
3x25+3x16/3	34	78	4300
3x35+3x16/3	35	82	4800
3x50+3x16/3	如需更详细的参数，可来电订制If you need more detailed parameters, you can call us for customization
3x70+3x25/3
3x95+3x35/3
3x120+3x35/3
注：以上规格为常用型，可根据用户要求定制特殊规格Note: The above specifications are common types, and special specifications can be customized according to user requirements
