产品名称：ZR-KFFP Fluoroplastic High Temperature Cable
浏览：
添加时间：2025-04-10 15:15:32
推荐度：

介绍：

用于用电设备器具的控制接线路，长期工作温度为200℃，弯曲半径不小于电缆外径的8倍，有铠装或屏蔽的电缆应不小于电缆外径的15倍。适用于工矿企业、能源*门、供交流额定电压450/750伏以下控制、保护线路等高温场合使用的氟塑料绝缘、氟塑料护套控制电缆。

Control wiring for electrical equipment and appliances, with a long-term operating temperature of 200 ℃ and a bending radius not less than 8 times the outer diameter of the cable. For armored or shielded cables, the bending radius should not be less than 15 times the outer diameter of the cable. Fluoroplastic insulated and fluoroplastic sheathed control cables suitable for high temperature applications such as industrial and mining enterprises, energy gates, and control and protection circuits with AC rated voltage below 450/750 volts.

P1镀锡丝屏蔽、P2铜带屏蔽、P3铝/塑复合薄膜屏蔽、9钢丝编织铠装

P1 tin plated wire shielding, P2 copper tape shielding, P3 aluminum/plastic composite film shielding, 9 steel wire braided armor

举例：铜芯氟塑料绝缘氟塑料护套铜丝屏蔽控制软电缆，移动敷设用，额定电压450/750V、19芯、1.5mm2表示为：

Example: Copper core fluoroplastic insulated fluoroplastic sheathed copper wire shielded control flexible cable, for mobile installation, rated voltage 450/750V, 19 cores, 1.5mm2 expressed as:

KFFRP-450/750V 19*1.5mm2

铜芯氟塑料绝缘氟塑料护套控制电缆，固定敷设用，额定电压450/750V、7芯、1.5mm2表示为：

Copper core fluoroplastic insulated fluoroplastic sheathed control cable, for fixed installation, rated voltage 450/750V, 7-core, 1.5mm2 expressed as:

KFF-450/750V 7*1.5mm2


型号model	导体标称截面Nominal cross-section of conductor mm2
0.5	0.75	1.0	1.5	2.5	4	6
芯数 CORE
KFF KFFP	-	2-19	2-12
KFFP2	-	2-19	2-12
KFFR	2-19	2-12
KFFRP	2-19	2-12
KFF9F	-	2-19	2-12
注：推荐的芯数系列为Note: The recommended chip count series is：2、3、4、5、7、8、10、12、14、16、19芯
