产品名称：high temperature and fire-resistant cablesABHBR
浏览：
添加时间：2025-04-29 13:53:17
推荐度：

介绍：

ABHBR,ABHBRP耐高温防火电缆
ABHBR, ABHBRP high temperature and fire-resistant cables
一：产品特点及用途
1： Product Features and Applications
ABHBR,ABHBRP电缆适用于发电、冶金等高温、防火、防腐等恶劣环境下移动电器用电气连接或动力传输。
ABHBR and ABHBRP cables are suitable for electrical connections or power transmission of mobile electrical appliances in harsh environments such as power generation, metallurgy, high temperature, fire prevention, and corrosion prevention.
二：产品执行标准
2： Product execution standards
Q/HHTZH009.3
Q/HHTZH009.3
耐火特性符合GB12666.6-90要求(IEC331)
Fire resistance characteristics meet the requirements of GB12666.6-90 (IEC331)
三：使用特性安徽中盛电气集团有限公司（Anhui Zhongsheng Electric Group Co., Ltd）
3： Usage characteristics
1．交流额定电压： 1KV及以下
1. Rated AC voltage: 1KV and below
***高使用温度：一种-40-500℃
Maximum operating temperature: -40-500 ℃
一种-40-800℃
A temperature range of -40-800 ℃
2．耐火特性：火焰温度950-1000℃、燃烧时间90min、附加额定电压3A电流
2. Fire resistance characteristics: flame temperature 950-1000 ℃, combustion time 90min, additional rated voltage 3A current
四：耐高温防火电缆型号及名称安徽中盛电气集团有限公司（Anhui Zhongsheng Electric Group Co., Ltd）
4： Model and name of high-temperature resistant and fire-resistant cable

型号Model	产品名称product name
ABHBR	耐高温防火软电缆High temperature resistant and fire-resistant flexible cable
ABHBRP	耐高温屏蔽防火软电缆High temperature resistant shielded fireproof flexible cable
备注：阻燃聚氯乙烯护套型号前加ZR，铠装电缆型号后加22Note: ZR should be added before the flame-retardant PVC sheath model, and 22 should be added after the armored cable model 安徽中盛电气集团有限公司（Anhui Zhongsheng Electric Group Co., Ltd）

五：主要技术指标Specification

性能项目Performance project	单位unit	技术指标TECHNICAL INDEX
20℃导体直流电阻Direct current resistance of conductor≤	Ω/km	参照表reference table
试验电压 testing voltage		3.5/5min
绝缘电阻 insulation resistance	MΩ/km	500
耐火特性Fire resistance characteristics		GB12666.6A类或B类Class 6A or Class B
阻燃特性Flame retardant properties		GB12666.5A类或B类Class 5A or Class B

六：基本电缆规格及结构参数Basic cable specifications and structural parameters 安徽中盛电气集团有限公司（Anhui Zhongsheng Electric Group Co., Ltd）

规格specifications mm2	近似外径Approximate outer diameter(mm)	规格specifications mm2	近似外径Approximate outer diameter(mm)
2*1.5	10.0
3*1.5	10.2
3*2.5	12.5	32.5+11.5	14.0
3*4	14.2	34+12.5	15.7
3*6	16.5	36+14	17.5
3*10	17.5	310+16	20.0
3*16	20.5	316+110	22.8
3*25	23.9	325+11	26.5
