产品名称：Generator rotor high-voltage insulated cable WDZ-YJGFP22
浏览：
添加时间：2025-05-07 10:22:15
推荐度：

介绍：

一：电缆型号规格结构

1： Cable model, specification, and structure

型号规格WDZ-YJGFP22-3KV 4x4 ；优质纯铜导体，绝缘采用合成耐高压新型材料，铜丝编织屏蔽，铠装，

Model and specification WDZ-YJGFP22-3KV 4x4; High quality pure copper conductor, insulated with synthetic high-voltage resistant new materials, copper wire braided shielding, armor,

护套使用阻燃合成高性能新型材料，电缆具有阻燃防老化，耐高压使用寿命长等特点。

The sheath is made of flame-retardant synthetic high-performance new materials, and the cable has the characteristics of flame retardancy, anti-aging, high voltage resistance, and long service life.

二：产品特点及用途

2： Product Features and Applications

本产品适用于交流额定电压3KV动力装置及电力线路中传输用，高绝缘电缆具有**的耐热机械性能，优异的电气性能和耐化学腐蚀性能等优点，因此广泛应用于电力、石化、冶金等企业。

This product is suitable for transmission in AC rated voltage 3KV power devices and power lines. High insulation cables have the advantages of * * heat-resistant mechanical performance, excellent electrical performance, and chemical corrosion resistance. Therefore, they are widely used in power, petrochemical, metallurgical and other enterprises.

低烟无卤电缆基本型号及名称

Basic models and names of low smoke halogen-free cables

型号名称

Model name

DLD-KVV 铜芯低烟低卤聚氯乙烯绝缘和护套控制电缆

DLD-KVV copper core low smoke and low halogen polyvinyl chloride insulated and sheathed control cable

DLD-KVVP 铜芯低烟低卤聚氯乙烯绝缘和护套铜网编织屏蔽控制电缆

DLD-KVVP copper core low smoke and low halogen polyvinyl chloride insulated and sheathed copper mesh braided shielded control cable

DLD-KVV22 铜芯低烟低卤聚氯乙烯绝缘和护套钢带铠装控制电缆

DLD-KVV22 copper core low smoke and low halogen polyvinyl chloride insulated and sheathed steel tape armored control cable

WLD-KJEG 铜芯无卤低烟交联聚烯烃绝缘热固性护套控制电缆

WLD-KJEG Copper Core Halogen Free Low Smoke Cross linked Polyolefin Insulated Thermosetting Sheath Control Cable

WLD-KJEGP 铜芯无卤低烟交联聚烯烃绝缘热固性护套铜网屏蔽控制电缆

WLD-KJEGP copper core halogen-free low smoke cross-linked polyolefin insulated thermosetting sheathed copper mesh shielded control cable

WLD-KJEGP2-22 铜芯无卤低烟交联聚烯烃绝缘热固性护套铜带屏蔽钢带铠装控制电缆

WLD-KJEGP2-22 copper core halogen-free low smoke cross-linked polyolefin insulation thermosetting sheath copper tape shielding steel tape armored control cable

WLD-KJES 铜芯无卤低烟交联聚烯烃绝缘热塑性护套控制电缆

WLD-KJES copper core halogen-free low smoke cross-linked polyolefin insulated thermoplastic sheathed control cable

WLD-KJESP 铜芯无卤低烟交联聚烯烃绝缘热塑性护套铜网屏蔽控制电缆

WLD-KJESP copper core halogen-free low smoke cross-linked polyolefin insulated thermoplastic sheathed copper mesh shielded control cable

WLD-KJES22 铜芯无卤低烟交联聚烯烃绝缘热塑性护套钢带铠装控制电缆

WLD-KJES22 copper core halogen-free low smoke cross-linked polyolefin insulated thermoplastic sheathed steel tape armored control cable

DLD-KSF 铜芯低烟低卤热塑性绝缘热塑体护套控制电缆

DLD-KSF copper core low smoke and low halogen thermoplastic insulated thermoplastic sheathed control cable

DLD-KSFP 铜芯低烟低卤热塑性绝缘热塑体护套铜网屏蔽控制电缆

DLD-KSFP copper core low smoke and low halogen thermoplastic insulated thermoplastic sheathed copper mesh shielded control cable

DLD-KSFP2-22 铜芯低烟低卤热塑性绝缘热塑体护套铜带屏蔽钢带铠装控制电缆

DLD-KSFP2-22 Copper Core Low Smoke and Low Halogen Thermoplastic Insulation Thermoplastic Sheath Copper Tape Shielding Steel Tape Armored Control Cable

低烟无卤电缆型号代号、名称及含义

Low smoke halogen-free cable model code, name and meaning

项目代号含义

Meaning of project code

系列代号 DLD

Series code DLD

WLD

K 低烟低卤

K low smoke and low halogen

低烟无卤

LSZH

控制电缆
