产品名称：Steel belt armored silicone rubber control cable KGG22
浏览：
添加时间：2025-09-28 09:57:15
推荐度：

介绍：

本产品适用于钢铁、冶炼、电厂、焦化厂、航空、冶金机械、石油化工等高温工业中，额定电压450/750V及以下的控制及监控回路中。它具有优良的耐高温、阻燃、耐辐射、耐老化、耐臭氧、防水等特性同时具有很好的耐寒性、耐候性。 This product is suitable for control and monitoring circuits with rated voltage of 450/750V and below in high-temperature industries such as steel, smelting, power plants, coking plants, aviation, metallurgical machinery, and petrochemicals. It has excellent characteristics such as high temperature resistance, flame retardancy, radiation resistance, aging resistance, ozone resistance, waterproofing, and also has good cold resistance and weather resistance. 一、执行标准 1、 Execution standards 采用QB/T341181-0095 Adopting QB/T341181-0095 二、使用条件 2、 Usage conditions 1.工作温度-50℃~180℃推荐弯曲半径不小于电缆外径的6倍 1. Working temperature -50 ℃~180 ℃. It is recommended that the bending radius should not be less than 6 times the outer diameter of the cable 2.有优良的耐氧、耐臭氧、耐紫外线照射性能，长期在室外使用不发生龟裂 2. It has excellent resistance to oxygen, ozone, and ultraviolet radiation, and will not crack after long-term outdoor use 3.有的电性能、耐电晕性和耐电弧性也非常好 3. Some have excellent electrical performance, corona resistance, and arc resistance 4.有优良的物理机械性能，在150℃高温下，其机械性能远远优于通用橡胶电缆，具有良好的耐化学物质性能、耐燃料油及油类性能。 4. It has excellent physical and mechanical properties. At a high temperature of 150 ℃, its mechanical properties are far superior to general rubber cables, and it has good resistance to chemical substances, fuel oil, and oil. 5.无臭、无味、无毒，具有低表面活性和低吸湿性性能。 5. Odorless, odorless, non-toxic, with low surface activity and low moisture absorption properties. 三、型号名称及使用范围 3、 Model name and scope of use

型号名称 Model Name 主要使用范围 Main application scope KGG KGG 铜芯硅橡胶绝缘硅橡胶护套控制电缆 Copper core silicone rubber insulated silicone rubber sheathed control cable 敷设在室内、电缆沟、管道固定场合 Installed indoors, in cable trenches, and in fixed pipeline locations KGGP KGGP 铜芯硅橡胶绝缘硅橡胶护套编织屏蔽控制电缆 Copper core silicone rubber insulated silicone rubber sheathed braided shielding control cable 敷设在室内、电缆沟、管道等要求屏蔽的固定场合 Installed indoors, in cable trenches, pipelines, and other fixed locations that require shielding KGGP2 KGGP2 铜芯硅橡胶绝缘硅橡胶护套铜带屏蔽控制电缆 Copper core silicone rubber insulated silicone rubber sheathed copper tape shielded control cable 同上 Ditto. KGG22 KGG22 铜芯硅橡胶绝缘硅橡胶护套钢带屏蔽控制电缆 Copper core silicone rubber insulated silicone rubber sheathed steel strip shielded control cable 敷设在室内、电缆沟、管道、直埋等能承受较大的机械拉力等固定场合 Installed indoors, in cable trenches, pipelines, direct burial, and other fixed locations that can withstand significant mechanical tension KGG32 KGG32 铜芯硅橡胶绝缘硅橡胶护套细钢丝铠装控制电缆 Copper core silicone rubber insulated silicone rubber sheathed thin steel wire armored control cable 敷设在室内、电缆沟、管道、竖井等能承受较大机械拉力等固定场合 Installed indoors, in cable trenches, pipelines, vertical shafts, and other fixed locations that can withstand significant mechanical tension KGGR KGGR 铜芯硅橡胶绝缘硅橡胶护套控制软电缆 Copper core silicone rubber insulated silicone rubber sheathed control flexible cable 敷设在室内移动要求柔软等场合 Laying in indoor environments where flexibility is required for mobility KGGRP KGGRP 铜芯硅橡胶绝缘硅橡胶护套编织屏蔽控制软电缆 Copper core silicone rubber insulated silicone rubber sheathed braided shielding control flexible cable 敷设在室内移动要求柔软、屏蔽等场合 Installed indoors for mobile applications that require softness, shielding, and other features
