产品名称：Flame retardant frequency conversion cableZRC-BPYJVRP
浏览：
添加时间：2025-11-27 10:31:21
推荐度：

介绍：

描述：ZRC-BPYJVRP-0.6/1KV变频电缆应用范围：适用于造纸、冶金、纺织、金属加工、矿山、铁路和食品加工等行业。变频电缆主要用于变频电源和变频电机之间连接用的电缆，以及额定电压1kV及以下的输配电线路中，作输送电能用。

Description: ZRC-BPYJVRP-0.6/1KV variable frequency cable Application scope: Suitable for industries such as papermaking, metallurgy, textile, metal processing, mining, railway, and food processing. Variable frequency cables are mainly used for connecting cables between variable frequency power supplies and variable frequency motors, as well as for transmitting electrical energy in transmission and distribution lines with a rated voltage of 1kV or below.

ZRC-BPYJVRP-0.6/1KV变频电缆允许温度及工作电压

ZRC-BPYJVRP-0.6/1KV Variable Frequency Cable Allowable Temperature and Operating Voltage

1、交联聚乙烯绝缘变频电缆允许导体连续工作zui高温度90℃，短路时zui高温度250℃。硅橡胶

1. Cross linked polyethylene insulated variable frequency cables allow conductors to operate continuously at a maximum temperature of 90 ℃, and during short circuits at a maximum temperature of 250 ℃. silicone rubber

zui高温度150℃，短路时zui高温度250℃。

The maximum temperature is 150 ℃, and the maximum temperature during short circuit is 250 ℃.

2、交联型变频电缆在运输、储存、辐射、搬运和作业时自由弯曲≥+5℃，固定敷设：≥0℃。硅橡

2. Cross linked variable frequency cables can be freely bent at ≥+5 ℃ during transportation, storage, radiation, handling, and operation, and can be fixedly laid at ≥ 0 ℃. Silicone rubber

辐射、搬运和作业时自由弯曲≥-20℃，固定敷设：≥-25℃。

Free bending during radiation, handling, and operation: ≥ -20 ℃, fixed installation: ≥ -25 ℃.

3、电缆弯曲半径为电缆直径的12倍，软电缆为电缆直径的6倍。

3. The bending radius of the cable is 12 times the diameter of the cable, and the bending radius of the flexible cable is 6 times the diameter of the cable.

4、额定电压为600/1000V，交流试验电压3500V。

4. The rated voltage is 600/1000V, and the AC test voltage is 3500V.

ZRC-BPYJVRP-0.6/1KV变频电缆3*95+3*16产品特点

ZRC-BPYJVRP-0.6/1KV Variable Frequency Cable 3 * 95+3 * 16 Product Features

1、较低的有效电容；

1. Lower effective capacitance;

2、具有屏蔽性能，高密度编织屏蔽及复合屏蔽设计使电缆具有良好的抗电磁干扰、电磁辐射的性

2. With shielding performance, high-density braided shielding and composite shielding design make the cable have good resistance to electromagnetic interference and radiation

备的应用。

Prepared applications.

3、较低且均匀的正（逆）序和零序阻抗，与普通四芯电缆相比改善了供电品质：该电缆含有屏蔽

3. Lower and uniform positive (reverse) and zero sequence impedances improve power supply quality compared to ordinary four core cables: the cable contains shielding

RX是对屏蔽抗感应和电容耦合的有效性的量度，低传输阻抗可提供良好的电磁相容性。

RX is a measure of the effectiveness of shielding against induction and capacitive coupling, and low transmission impedance can provide good electromagnetic compatibility.

4、*对称的三芯设计，更好的电磁兼容性，比四芯电缆更好的性能。三根耐侯耐温树脂绝缘线芯

4. Symmetrical three core design, better electromagnetic compatibility, and better performance than four core cables. Three weather resistant and temperature resistant resin insulated wire cores

真正的同心结构。

A true concentric structure.

5、*屏蔽了高次谐波电流分量对其他控制电路的干扰。

5. Shielded the interference of high-order harmonic current components on other control circuits.

6、屏蔽层的截面设计与主线芯达到一定比例，可用作PE接地线芯。

6. The cross-sectional design of the shielding layer is proportional to the main wire core and can be used as a PE grounding wire core.

7、电缆导体的zui高工作温度与绝缘材料相适应。

7. The maximum working temperature of cable conductors is compatible with the insulation material.

8、采用低烟无卤阻燃护层，电缆在发生火灾时具有发烟少，使用更安全更环保，也可以制造成耐

8. By using a low smoke halogen-free flame retardant protective layer, the cable emits less smoke in the event of a fire, making it safer and more environmentally friendly to use. It can also be manufactured to be durable

9、试验电压：3.5kV/5min；脉冲雷击电压：正负10次，40kV不击穿。

9. Test voltage: 3.5kV/5min; Pulse lightning voltage: positive or negative 10 times, 40kV without breakdown.

型号说明：

Model Description:

型号名称适用场所

Model Name Applicable Location

BPYJVP 交联聚乙烯绝缘聚氯乙烯护套铜丝编织屏蔽变频器用电缆

BPYJVP cross-linked polyethylene insulated PVC sheathed copper wire braided shielded frequency converter cable

有较高屏蔽要求的场所

Places with high shielding requirements

BPYJVP2交联聚乙烯绝缘聚氯乙烯护套铜带屏蔽变频器用电缆

BPYJVP2 cross-linked polyethylene insulated polyvinyl chloride sheathed copper tape shielded frequency converter cable
