产品名称：WDZC-FSY11-YJLHY23 Al-Alloy Power Cable, LSZH, FR, Anti-Rode
浏览：
添加时间：2026-05-19 09:55:57
推荐度：

介绍：

WDZC-FSY11-YJLHY23低烟无卤防鼠蚁铝合金电缆是一款专为高难度、高要求基建场景打造的“全能型”电力传输产品。作为传统铜芯电缆的高性价比替代品，本产品wm****融合了8000系铝合金的轻便经济与多重特种防护技术。无论是在人员密集的商业中心，还是在鼠蚁横行、环境恶劣的地下管廊，这款电缆都能提供稳定、安全、长效的电力保障。

Product Overview (SEO Friendly Section)

The WDZC-FSY11-YJLHY23 LSZH Anti-Rodent & Anti-Termite Aluminum Alloy Cable is an "all-round" power transmission product engineered for challenging and high-demand infrastructure scenarios. Serving as a cost-effective alternative to traditional copper core cables, this product perfectly integrates the lightweight economy of 8000 series aluminum alloy with multiple specialized protection technologies. Whether deployed in densely populated commercial centers or harsh underground pipe galleries prone to rodent and termite infestations, this cable ensures stable, safe, and long-lasting power supply.

Core Selling Points (Structured for Baidu Crawling & Quick Reading)

Special Biological Protection: Say Goodbye to Rodent & Termite Damage, Reduce O&M Costs

主动防御： 针对直埋或管廊敷设中常见的生物侵害，电缆外层特别添加了环保型驱避剂并采用高硬度护套材料。

Active Defense: Targeting common biological threats during direct burial or pipe gallery installation, the cable's outer layer incorporates environmentally friendly repellents and utilizes a high-hardness sheath material.

长效保护： 有效抵御鼠类和白蚁的啃咬侵蚀，杜绝因绝缘层破损导致的短路跳闸，大幅延长线路使用寿命。

Long-term Protection: Effectively resists biting and erosion by rodents and termites, preventing short circuits and tripping caused by insulation damage, thereby significantly extending the service life of the line.

High-Level Fire Safety: LSZH Flame Retardant, Securing the Lifeline

WDZC级阻燃： 采用优质交联聚乙烯（XLPE）绝缘和低烟无卤（LSZH）聚烯烃护套，遇火不燃、离火自熄。

WDZC Class Flame Retardant: Utilizes high-quality cross-linked polyethylene (XLPE) insulation and low-smoke zero-halogen (LSZH) polyolefin sheathing, ensuring non-combustibility upon fire exposure and self-extinguishment once the source is removed.

环保无毒： 火灾发生时******释放卤酸等有毒气体，且发烟量极低，为人员疏散和消防救援争取宝贵的“黄金时间”。

Eco-Friendly & Non-Toxic: Absolutely no release of toxic gases such as halogen acids during a fire, coupled with extremely low smoke density, securing precious "golden time" for personnel evacuation and fire rescue.

Unbreakable Mechanical Strength: Steel Tape Armor, Pressure & Impact Resistant

内置钢带铠装（23型）： 如同为电缆穿上“******衣”，具备******的抗压、抗冲击及抗拉能力。

Built-in Steel Tape Armor (Type 23): Acts like a "bulletproof vest" for the cable, providing excellent resistance against pressure, impact, and tension.

适应复杂地形： 无惧地下石块挤压和施工外力破坏，wm****胜任直埋、隧道、桥梁等多种严苛敷设环境。

Adapts to Complex Terrain: Withstands squeezing from underground rocks and external construction damage, perfectly suited for harsh laying environments such as direct burial, tunnels, and bridges.

Revolutionary Aluminum Alloy Conductor: Cost-Effective & Easy Installation

轻盈强韧： 采用优质铝合金导芯（LH），密度仅为纯铜的1/3，大幅减轻电缆自重。

Lightweight & Tough: Adopts high-quality aluminum alloy conductor (LH) with a density only one-third that of pure copper, significantly reducing the cable's dead weight.

经济效益***大化： 在同等载流量下，显著降低原材料成本；重量轻、柔韧性好，单人即可进行弯曲敷设，*********压缩工程造价与施工周期。

Maximized Economic Benefits: Significantly reduces raw material costs under equivalent current-carrying capacity; lightweight and flexible, allowing single-person bending and installation, comprehensively compressing project costs and construction cycles.

Typical Application Scenarios (Covering High-Frequency Procurement Needs)

市政工程： 城市地下综合管廊、路灯照明主干线。

Municipal Engineering: Urban underground comprehensive pipe galleries, street lighting main lines.

商业地产： 大型商业综合体、高层写字楼、医院、学校。

Commercial Real Estate: Large-scale commercial complexes, high-rise office buildings, hospitals, schools.

交通枢纽： 地铁站、高铁站、机场航站楼（对消防要求******的场所）。

Transportation Hubs: Subway stations, high-speed rail stations, airport terminals (venues with extremely high fire safety requirements).

新能源基建： 光伏电站、风电场集电线路、储能系统。

New Energy Infrastructure: Photovoltaic power plants, wind farm collector lines, energy storage systems.

工业制造： 自动化工厂、大型机械制造车间配电。

Industrial Manufacturing: Automated factories, large machinery manufacturing workshop power distribution.

Basic Product Attributes (Ideal for B2B Platform Attribute Fields)

属性名称 (Attribute Name)	属性值 (Attribute Value)
产品名称 (Product Name)	WDZC-FSY11-YJLHY23 低烟无卤防鼠蚁铝合金电缆 WDZC-FSY11-YJLHY23 LSZH Anti-Rodent & Anti-Termite Aluminum Alloy Cable
导体材质 (Conductor Material)	8000系铝合金 (8000 Series Aluminum Alloy)
绝缘材料 (Insulation Material)	交联聚乙烯 (XLPE)
护套材料 (Sheath Material)	低烟无卤聚烯烃 (LSZH Polyolefin)
铠装方式 (Armor Type)	钢带铠装 (Steel Tape Armor)
特殊功能 (Special Features)	防鼠 (Anti-Rodent)、防白蚁 (Anti-Termite)
执行标准 (Standards Compliance)	国标/行标/企标 (National/Industry/Enterprise Standards)
额定电压 (Rated Voltage)	0.6/1kV, 8.7/10kV, 26/35kV 等 (Customizable)
