产品名称：WDZC-FSY11-KVVP2-23 LSZH Anti-Rodent & Anti-Termite Cont
浏览：
添加时间：2026-05-19 10:57:55
推荐度：

介绍：

WDZC-FSY11-KVVP2-23 防鼠蚁电缆是一种专为复杂工业环境设计的特种控制电缆。该电缆在具备优异电气性能与机械防护能力的同时，通过复合防鼠蚁结构设计，有效解决了电缆在户外、地下或潮湿环境中被生物破坏的行业痛点。其采用的低烟无卤护套材料在火灾发生时能大幅降低有毒烟雾排放，是现代工业与基础设施建设中关键的安全连接组件。

WDZC-FSY11-KVVP2-23 Anti-Rodent & Anti-Termite Cable Product Description

The WDZC-FSY11-KVVP2-23 Anti-Rodent & Anti-Termite Cable is a specialized control cable engineered for complex industrial environments. While delivering excellent electrical performance and mechanical protection, it incorporates a composite anti-rodent and anti-termite structural design to effectively address the industry-wide challenge of biological damage in outdoor, underground, or humid settings. Utilizing a Low Smoke Zero Halogen (LSZH) sheath material, it significantly reduces toxic smoke emissions during fire incidents, serving as a critical safety link in modern industrial and infrastructure projects.

核心特点 (Core Features)

1. 生物防护性能 (Biological Protection Performance)

主动防御机制：电缆外层采用特种防护配方或物理硬化处理，能够有效抵御鼠类啃咬和白蚁蛀蚀，显著降低因生物侵害导致的短路与停电风险。
长效环境适应性：防护层性质稳定，不溶于水且不挥发，在长期埋地或管廊敷设环境中保持持久的驱避效果。
1. Biological Protection Performance
Active Defense Mechanism: The outer layer employs specialized protective compounds or physical hardening treatments to effectively resist gnawing by rodents and boring by termites, significantly mitigating the risk of short circuits and power outages caused by biological damage.
Long-term Environmental Adaptability: The protective layer remains chemically stable, insoluble in water, and non-volatile, maintaining persistent repellent efficacy in long-term buried or utility tunnel installation environments.

2. 阻燃与环保特性 (Flame Retardant & Environmental Properties)

WDZC 级安全标准：符合无卤、低烟、阻燃C类标准。在燃烧状态下，电缆不释放卤酸等腐蚀性气体，且烟密度极低，为人员疏散和应急救援提供清晰的能见度。
绿色材料应用：护套材料不含铅、镉等重金属，符合 RoHS 环保指令要求。
2. Flame Retardant & Environmental Properties
WDZC Safety Standard: Complies with halogen-free, low smoke, and Class C flame retardant standards. Under combustion conditions, the cable does not emit corrosive halogen acid gases and exhibits minimal smoke density, providing clear visibility for personnel evacuation and emergency rescue operations.
Green Material Application: The sheath material is free from heavy metals such as lead and cadmium, meeting the requirements of RoHS environmental directives.

3. 电气与屏蔽性能 (Electrical & Shielding Performance)

抗电磁干扰：采用铜带屏蔽结构，形成法拉第笼效应，有效隔离外界强电磁场干扰，确保控制信号传输的准确性与稳定性。
稳定传输：适用于额定电压 450/750V 及以下的控制、监视回路及保护线路。
3. Electrical & Shielding Performance
Electromagnetic Interference Resistance: Featuring a copper tape shielding structure that creates a Faraday cage effect, effectively isolating external strong electromagnetic field interference and ensuring the accuracy and stability of control signal transmission.
Stable Transmission: Suitable for control, monitoring circuits, and protection lines with a rated voltage of 450/750V and below.

4. 机械防护能力 (Mechanical Protection Capability)

钢带铠装加固：内层设置钢带铠装层，具备******的抗压、抗冲击及抗拉能力，可适应直埋敷设或存在重型机械作业的严苛场景。
4. Mechanical Protection Capability
Steel Tape Armor Reinforcement: An inner steel tape armor layer provides exceptional resistance to compression, impact, and tension, adapting to harsh installation scenarios involving direct burial or operations with heavy machinery.

技术参数 (Technical Parameters)

参数项目 (Parameter)	参数值 (Specification)
产品名称 (Product Name)	WDZC-FSY11-KVVP2-23 防鼠蚁控制电缆 WDZC-FSY11-KVVP2-23 Anti-Rodent & Anti-Termite Control Cable
额定电压 (Rated Voltage)	450/750V
导体材质 (Conductor Material)	退火铜 (Annealed Copper)
绝缘材料 (Insulation Material)	聚氯乙烯 (PVC) / 交联聚乙烯 (XLPE)
屏蔽结构 (Shielding)	铜带屏蔽 (Copper Tape Shield)
铠装结构 (Armor Structure)	双层钢带铠装 (Double Steel Tape Armor)
护套特性 (Sheath Characteristics)	低烟无卤、防鼠、防白蚁 (LSZH, Anti-Rodent, Anti-Termite)
工作温度 (Operating Temp.)	导体长期工作温度 ≤ 70℃ / 90℃ (依绝缘层而定) Long-term conductor operating temperature ≤ 70℃ / 90℃ (depending on insulation)

典型应用场景 (Typical Application Scenarios)

能源电力 (Energy & Power)：发电厂、变电站、新能源（光伏、风电）项目的控制与保护线路。
重工业制造 (Heavy Industry)：冶金、化工、石油开采等存在腐蚀性气体或鼠蚁滋生的重工业环境。
基础设施 (Infrastructure)：城市轨道交通（地铁）、高铁信号控制系统，以及智能楼宇的消防安保回路。
通信交通 (Telecommunications & Transport)：通信基站的电源与控制连接，隧道照明及监控系统。
Typical Application Scenarios
Energy & Power: Control and protection lines for power plants, substations, and new energy projects (photovoltaic, wind power).
Heavy Industry: Heavy industrial environments prone to corrosive gases or rodent/termite infestations, such as metallurgy, chemical processing, and petroleum extraction.
Infrastructure: Urban rail transit (subway), high-speed rail signaling systems, and fire safety/security circuits in smart buildings.
Telecommunications & Transport: Power and control connections for communication base stations, tunnel lighting, and monitoring systems.
