产品名称：FSY-YSY 2×14# Rodent & Termite Resistant Cable
浏览：
添加时间：2026-05-22 10:13:36
推荐度：

介绍：

FSY-YSY 2×14# 防鼠防蚁电缆

FSY-YSY 2×14# Rodent & Termite Resistant Cable

FSY-YSY 2×14# 是一款额定电压 0.6/1kV 的铜芯防鼠防蚁特种电缆。该产品采用环保型聚烯烃护套，通过添加专用防鼠剂与防白蚁剂，专为鼠害、蚁害严重的环境设计，广泛应用于地下管廊、隧道及潮湿腐蚀性场所的电力传输。

FSY-YSY 2×14# is a copper-core rodent and termite resistant cable with a rated voltage of 0.6/1kV. It utilizes an environmentally friendly polyolefin sheath with specialized rodent and termite repellents, designed for environments with severe pest infestations such as underground utility tunnels, subways, and corrosive damp locations.

一、产品规格概要

I. Product Specification Summary

项目	具体描述
完整型号	FSY-YSY 2×14# (或 2×14AWG)
产品类型	铜芯聚烯烃绝缘及护套防鼠防蚁电缆
额定电压	0.6/1 kV
芯数与截面	2 芯，标称截面 14# (约 2.08 mm²)
典型结构	铜导体 + 聚烯烃绝缘 + 聚烯烃防鼠蚁护套
Item	Specific Description
:---	:---
Complete Model	FSY-YSY 2×14# (or 2×14AWG)
Product Type	Copper Conductor, Polyolefin Insulated & Sheathed Rodent & Termite Resistant Cable
Rated Voltage	0.6/1 kV
Core Number & Cross-Section	2 cores, nominal cross-sectional area 14# (approx. 2.08 mm²)
Typical Structure	Copper Conductor + Polyolefin Insulation + Polyolefin Rodent/Termite Resistant Sheath

二、主要技术参数

II. Main Technical Parameters

参数类别	技术说明
导体	铜导体，截面 14# (约 2.08 mm²)，柔韧性好
绝缘/护套	环保型聚烯烃材料，耐腐蚀、耐潮湿
防鼠蚁机制	护套添加环保驱避剂 (如 DH-600/DH-203)，驱避鼠类、灭杀白蚁
温度范围	长期工作 ≤+90℃，环境适应 -25℃ ~ +45℃
弯曲半径	多芯电缆 ≥15D (D为电缆外径)
Parameter Category	Technical Description
:---	:---
Conductor	Copper conductor, 14# gauge (approx. 2.08 mm²), good flexibility
Insulation/Sheath	Eco-friendly polyolefin, corrosion and moisture resistant
Pest Resistance	Sheath contains eco-repellents (e.g., DH-600/DH-203) to deter rodents and kill termites
Temperature Range	Long-term operating ≤+90℃, ambient -25℃ ~ +45℃
Bending Radius	Multi-core cable ≥15D (D is outer diameter)

三、产品核心特点

III. Core Product Features

双重防护：护套中添加防鼠剂与防白蚁剂，通过驱避或灭杀机制，有效防止鼠类啃咬与白蚁蛀蚀，保护电缆结构完整。
环保安全：采用低毒或无毒环保添加剂，对土壤、空气污染小，符合绿色电缆要求。
环境适应强：聚烯烃材质具备优异的耐候性、耐磨性及耐化学腐蚀性，适用于潮湿、酸碱等复杂环境。
电气性能稳定：绝缘电阻大，耐电压性能好，确保在恶劣环境下电力传输的可靠性。
Dual Protection: The sheath contains rodent and termite repellents that deter chewing and boring through repellency or lethal action, ensuring structural integrity.
Environmental Safety: Utilizes low-toxicity or non-toxic eco-friendly additives, minimizing pollution and meeting green cable standards.
Environmental Resistance: Polyolefin material offers excellent weather, abrasion, and chemical corrosion resistance, suitable for damp and corrosive conditions.
Stable Electrical Performance: High insulation resistance and good voltage withstand capability ensure reliable power transmission in harsh environments.

四、典型应用领域

IV. Typical Application Fields

地下基础设施：城市地下综合管廊、电缆隧道、地铁及地下变电站，防止鼠蚁破坏导致短路。
工业与能源：化工园区、发电厂、污水处理厂等存在腐蚀与生物危害的场所。
交通设施：铁路信号系统、公路隧道照明、桥梁涵洞的供电线路。
农林水利：农田灌溉、泵站、水利枢纽等鼠蚁活动频繁的户外或半户外区域。
Underground Infrastructure: Urban utility tunnels, cable tunnels, subways, and underground substations to prevent pest-induced failures.
Industrial & Energy: Chemical plants, power plants, and wastewater treatment plants where corrosion and pests are concerns.
Transportation: Railway signaling, highway tunnel lighting, and bridge culvert power supply lines.
Agriculture & Water Conservancy: Farm irrigation, pumping stations, and hydraulic projects with high pest activity.
