产品名称：ZC-YJLHV22 1.8/3kV 3×240 Aluminum Alloy Armored Power Cable
浏览：
添加时间：2026-05-22 16:45:49
推荐度：

介绍：

ZC-YJLHV22 1.8/3kV 3×240 阻燃铝合金铠装电力电缆

ZC-YJLHV22 1.8/3kV 3×240 Flame Retardant Aluminum Alloy Armored Power Cable

ZC-YJLHV22 1.8/3kV 3×240 是一款额定电压为 1.8/3kV 的阻燃C类、铝合金导体、交联聚乙烯绝缘、钢带铠装中压电力电缆。该产品采用 3 芯 240mm² 大截面设计，专为 3kV 配电系统的固定敷设设计，具备优异的阻燃性能、机械防护能力和轻量化经济性，适用于工业园、矿山及新能源项目的电力主干线。

ZC-YJLHV22 1.8/3kV 3×240 is a Category C Flame Retardant, Aluminum Alloy Conductor, XLPE Insulated, Steel Tape Armored medium-voltage power cable with a rated voltage of 1.8/3kV. Featuring a large cross-section design of 3 cores × 240mm², it is specifically engineered for fixed installation in 3kV power distribution systems, offering excellent flame retardancy, mechanical protection, and lightweight cost-efficiency, making it suitable for industrial parks, mines, and power trunk lines in new energy projects.

一、主要技术参数（参考值）

I. Main Technical Parameters (Reference Values)

参数类别	技术指标
导体材料	AA-8000系列铝合金，紧压圆形绞合
导体直流电阻	≤ 0.125 Ω/km（20℃）
绝缘厚度	约 2.0 mm（交联聚乙烯，符合1.8/3kV等级）
护套厚度	约 2.6 mm（黑色PVC，阻燃型）
电缆外径	约 60 - 65 mm（因厂家工艺略有差异）
电缆重量	约 4300 kg/km（即每米约 4.3 kg）
温度范围	长期工作：-15℃ ~ +90℃（导体***高90℃）短路温度：≤ 250℃（持续时间5s）
***小弯曲半径	12D（D为电缆外径，约需 0.75 - 0.85 米空间）
Parameter Category	Technical Indicator
:---	:---
Conductor Material	AA-8000 series aluminum alloy, compacted circular stranded
Conductor DC Resistance	≤ 0.125 Ω/km (at 20℃)
Insulation Thickness	Approx. 2.0 mm (XLPE, compliant with 1.8/3kV rating)
Sheath Thickness	Approx. 2.6 mm (Black PVC, flame retardant type)
Cable Outer Diameter	Approx. 60 - 65 mm (varies slightly by manufacturer)
Cable Weight	Approx. 4300 kg/km (approx. 4.3 kg per meter)
Temperature Range	Long-term operation: -15℃ ~ +90℃ (Max. conductor temp. 90℃) Short-circuit temp.: ≤ 250℃ (Duration 5s)
Minimum Bending Radius	12D (D is outer diameter, requires approx. 0.75 - 0.85 m space)

二、产品核心特点

II. Core Product Features

轻量化与经济性：采用铝合金导体，相比同规格铜缆（YJV22）重量减轻约 40%，大幅降低运输、搬运及支架成本，工程造价更具优势。
双重安全防护：ZC阻燃特性可在火灾条件下抑制火焰蔓延；22钢带铠装结构提供强大的抗压、抗冲击能力，适合直埋、电缆沟及有机械外力风险的场所。
电气性能稳定：交联聚乙烯（XLPE）绝缘配合 1.8/3kV 中压设计，介电强度高，长期允许工作温度达 90℃，载流量大。
抗蠕变可靠：铝合金导体经过特殊合金化及退火处理，解决了纯铝导体易蠕变、连接处松动的历史难题，连接可靠性接近铜导体。
Lightweight & Cost-Effective: Utilizing an aluminum alloy conductor, it reduces weight by approximately 40% compared to equivalent copper cables (YJV22), significantly lowering transportation, handling, and support costs, thus offering greater economic advantages in project budgeting.
Dual Safety Protection: The ZC flame retardancy suppresses flame spread under fire conditions; the 22 steel tape armor structure provides robust crush and impact resistance, making it suitable for direct burial, cable trenches, and locations with risks of mechanical external forces.
Stable Electrical Performance: XLPE insulation combined with the 1.8/3kV medium-voltage design ensures high dielectric strength, a long-term allowable operating temperature of 90℃, and high current-carrying capacity.
Anti-Creep Reliability: The aluminum alloy conductor undergoes special alloying and annealing treatments, solving the historical issues of creep and loose connections associated with pure aluminum conductors, achieving connection reliability close to that of copper conductors.

三、典型应用场景

III. Typical Application Scenarios

工业配电干线：工厂、矿山、港口 3kV 供电系统中的主电源线路。
新能源集电：风力发电、光伏电站的场内集电线路。
城市基建：隧道、地铁、大型公共建筑（如机场、车站）的次级配电网络。
长距离供电：对成本敏感且需大截面输送电能的架空或直埋项目。
Industrial Power Distribution Trunk Lines: Main power supply lines in 3kV power supply systems for factories, mines, and ports.
New Energy Collection Networks: Intra-field collection lines for wind power and photovoltaic power stations.
Urban Infrastructure: Secondary power distribution networks for tunnels, subways, and large public buildings (e.g., airports, stations).
Long-Distance Power Supply: Overhead or direct burial projects requiring large cross-sections for power transmission where cost sensitivity is high.
